เครื่องรักษาอุณหภูมิช็อกโกแลต เทมเปอร์ริ่งควบคุมอุณหภูมิช็อกโกแลต รุ่น LEGEND
LEGEND TEMPERING CHOCOLATE MACHINERY
Professional chocolate tempering machine
Legend Professional chocolate tempering machine
Legend, new version of the Ghana chocolate tempering machine, with a digital control panel that increases versatility of use and economy of operation.
Volumetric dosing unit with foot pedal for controlling the flow of chocolate.
Heated low-voltage vibrating table.
Tempering machine capable of producing up to 90 kg of tempered chocolate per hour.
A restyled machine derived from the original Selmi Ghana model. With all its components upgraded it makes use of the latest systems.
- คุณลักษณะเกี่ยวกับเครื่อง
- คุณสมบัติเฉพาะทางเทคนิค
- วีดีโอเกี่ยวกับเครื่อง
- แคตตาล็อก
- ภาพผลงาน เครื่องติดตั้งจริงหน้างาน
- แสดงวิธีใช้เครื่อง สอนการใช้งาน การบำรุงรักษา
- เอกสารรับรอง
คุณลักษณะเกี่ยวกับเครื่อง
LEGEND TEMPERING CHOCOLATE MACHINERY
Professional chocolate tempering machine
Legend Professional chocolate tempering machine
Legend, new version of the Ghana chocolate tempering machine, with a digital control panel that increases versatility of use and economy of operation.
Volumetric dosing unit with foot pedal for controlling the flow of chocolate.
Heated low-voltage vibrating table.
Tempering machine capable of producing up to 90 kg of tempered chocolate per hour.
A restyled machine derived from the original Selmi Ghana model. With all its components upgraded it makes use of the latest systems.
Characteristics
Compact size with the option of being equipped with all Selmi accessories.
Ideal for chocolateries, patisseries, bakers and ice cream parlours.
Tempers 24 Kg of chocolate in 15 minutes.
New construction concepts resulting in lower energy consumption.
Option to modify to single phase 220V.
Option to modify to three-phase 220 V – 50/60 Hz.
Heated vibrating table 220 V 24 V.
คุณสมบัติเฉพาะทางเทคนิค
Mechanical Characteristics
| Overall dimensions | 500[L] x 875[W] x 1470[H] mm. |
| Empty weight | [Kg.] 159 |
| Material in contact with food | inox AISI 304L |
| Gaskets | PTFE |
| Tank capacity | [Kg.] 24 |
| No. of pivoting wheel4 |
Cooling System Characteristics
| Cooling group | [Fr/h] 1100 |
| Refrigerant gas | R452A |
| Refrigerant gas quantity | [g]410 |
| Coolant | [I]2, 5 |
| 70% water, 30% phosphate-free glycol |
Electrical characteristics
| Total installed power | [KW] 1, 6 |
| Supply voltage | [VAC] 400/220 |
| Number of phases | 1*/ 3 |
| Frequency | [Hz] 50 / 60 |
| Auxiliary voltage | [Vdc] +24 |
| Enclosure degree of protection | IP65 |
| Connection type: industrial plug | 16A – 5 poles |
Process Features
| Tank reducer ratio | 1 : 60 |
| Maximum mixer revolutions | [rpm] 23 |
| Hourly production | [kg/h] 90 |
